SIZING
Base Unit | KGA-8016-2GB | KGA-8018-2GB | KGA-8020-2GB |
---|---|---|---|
Weight Capacity | 250 lb | 250 lb | 250 lb |
Seat Width | 16” | 18” | 20” |
Seat Depth | 16” – 20” | 16” – 20” | 16” – 20” |
Tilt Angle Range | 0° – 45° | 0° – 45° | 0° – 45° |
Front Caster Diameter | 8” | 8” | 8” |
Seat-to-Floor Height w/20” Rear Wheels | 18.5” | 18.5” | 18.5” |
Seat-to-Floor Height w/Sold Seat Pan/22” Wheels | 19” | 19” | 19” |
Armrest Height | 11” – 15” | 11” – 15” | 11” – 15” |
Back Cane Height | 19” – 24” | 19” – 24” | 19” – 24” |
Back Angle Range | 90° – 110° | 90° – 110° | 90° – 110° |
Overall Width (Folded) | 12” | 12” | 12” |
Overall Width (20” Wheels) | 24” | 26” | 28” |
Footrest Hanger Angle | 70° | 70° | 70° |
Footrest Adjustment Range | 11.5” – 17” | 11.5” – 17” | 11.5” – 17” |
Footplate Size | 6.25” x 8” | 6.25” x 8” | 6.25” x 8” |
